Smart Engineering
and Production
Efficiency in panel building
Eplan – Rittal – Phoenix Contact
Contact us nowCooperation for engineering, automation, and system technology
Take a holistic approach to your processes in panel building. With Eplan, Rittal, and Phoenix Contact by your side, you have three strong partners who will work with you to achieve this.
Benefit from a longstanding collaboration that offers exceptional added value for consistent digitalization in panel building and switchgear manufacturing. All aspects are optimally coordinated, enabling us to provide you with smart solutions from electrical engineering all the way to the digitally-supported and automated production.
Open data standards for smooth production processes
For our cross-system interfaces and integrations, we use open data standards such as AutomationML and ECLASS. This enables the continuous flow of data for your product development and manufacturing right through to series production. Based on standard products, the production of batch size 1 becomes possible in your production. Furthermore, we actively promote the wider adoption and further development of standards concerning digital transformation for the entire industry.
Experience efficiency – along your entire process chain in panel building
From the initial preplanning in engineering and the digital twin for automated manufacturing through to flexible services for active system operation: we offer a joint consulting service and comprehensive portfolio of solutions for each process step. Experience efficiency firsthand: discover for yourself the unique advantages of the partnership initiative with Eplan, Rittal, and Phoenix Contact.
Experience efficiency
Find out how we can boost your efficiency and discover for yourself the unique advantages of our cooperation – both now and in the future.













References
W. Althaus AG
As far as W. Althaus AG is concerned, the secret to better efficiency in panel building and switchgear has for years been automation, plus data consistency for processes and a strong technology network with Eplan, Rittal and Phoenix Contact.

Ingela Ltd.
Ingela GmbH, from Bisingen in Germany, evolved from being solely a manufacturer of enclosures to a provider of engineering services for mechanical engineering thanks to Eplan. Since establishing its first Eplan workplace in 2013, the company has followed a straightforward policy: “We want to exploit the potential of automation fully” says Ingo Straub, Managing Partner of Ingela. This has set the stage for further stages of automation.

Alexander Bürkle
Improved design using digital twins. This sums up the principle by which Alexander Bürkle GmbH & Co. KG has recently been organising its engineering and assembly of control cabinets. A central prerequisite for this is the EPLAN Platform.
“For us, this speeds up control cabinet design considerably because the parts are selected according to a system of options. We also make the data available to customers on request, and there is hardly a cutomer who doesn‘t appreciate this service.“ Fabian Camek, Head of Electrical Design.

Ripploh Elektrotechnik & Engineering
All processes at Ripploh are highly digitized and, if possible, automated. The result: greater efficiency and speed, a lower error rate and more orders processed with the same number of employees.The data generated in the engineering department is used seamlessly to manage processes in the workshop. The 3D planning in EPLAN Pro Panel, for example, provides the data for the CNC machine used to machine panels and for fully automated wire processing.

Elpex AG
To automate the workshop processes, Elpex relies on the Perforex BC 1001 HS machining center and a Secarex AC 15 cutting center from Rittal Automation Systems. The optimized interaction between engineering and automated enclosure processing accelerates processes by up to 50 % - with increased product quality, optimized waste rates and lower costs.

Blumenbecker Automatisierungstechnik
Automation continues to forge ahead, including in the field of control cabinet manufacturing – and, with consistent communication between the configuration software and terminal strip assembly, Blumenbecker Automatisierungstechnik GmbH aims to further optimize its concept for control cabinet manufacturing 4.0. For this purpose, the company is considering the PROJECT complete software because the data processed by this software allow for individual terminal strip assembly and marking during the engineering process.

Have you missed one of our presentations?
No problem: We make our presentations exclusively available to you. Get insights into the solutions of Smart Engineering and Production:
– How cooperations create real added value
– The future of panel building: Digitalization leads to efficient processes
– Standardized interfaces open up paths for individual automation in production
About us
Eplan
Eplan provides software and service solutions in the fields of electrical, automation and mechatronic engineering. The company develops one of the world’s leading design software solutions for machine and panel builders. Both standardised as well as customised interfaces to ERP and PLM/PDM systems ensure data consistency along the whole value chain. Eplan was founded in 1984 and is part of the owner-operated Friedhelm Loh Group.

Eplan
"We need standardized data description models much earlier than in the engineering phase, for example when a manufacturing company formulates requirements for machine builders, panel builders or providers of automation solutions."
Sebastian Seitz, CEO at EPLAN

Rittal
Rittal is a leading global provider of solutions for industrial enclosures, power distribution, climate control and IT infrastructure, as well as software and services. Together with Eplan, Rittal optimizes the customer's entire value chain in control and switchgear manufacturing. The companies are part of the Friedhelm Loh Group, which generated revenues of €3 billion 2022 with more than 12,000 employees and more than 95 subsidiaries worldwide.

Rittal
"The strength of 'Smart Engineering and Production' is the joint striving for data consistency and efficiency throughout the entire life cycle of control and switchgear systems. Consistent data not only increases efficiency in planning and construction, but also extends its benefits more and more into the operation of the installations."
Uwe Scharf, Managing Director Business Units and Marketing

Phoenix Contact
Phoenix Contact offers innovative products, solutions and digitalization expertise for the electrification, networking, and automation of all sectors of the economy and infrastructure. The family-run company empowers industry and society to transform into a sustainable world with long-term growth prospects for everyone. Today, Phoenix Contact employs around 22,000 people worldwide, with sales of €3.6 billion in 2022.

Phoenix Contact
"Smart Engineering and Production is the massive key that ensures the competitiveness of our customers in switchgear engineering. In this, our goal is to make a seamless solution available to our customers, from engineering right through to innovative production systems.”
Dirk Görlitzer, COO at Phoenix Contact

Contact
Eplan – Rittal – Phoenix Contact

Standardized basis for consistent processes
A digital item description provides the basis for consistent processes – from planning in engineering right through to control cabinet manufacturing. It is created during the item’s design phase and describes all the features that are relevant for engineering, manufacturing, and service.
Comprehensive imaging of item data
The item features are available entirely in digital format. In the new EPLAN Data Portal, they are described in accordance with the uniform data standard, based on ECLASS. Up-to-date item data is always available in ECLASS format and can be obtained from the manufacturers. Rittal and Phoenix Contact provide high-quality, complete data in the EPLAN Data Portal.
Your advantages for greater efficiency:
- Comprehensive consulting from the provision of data right through to system operation for the end user
- Increased integration for all of your processes, thanks to the standardized database in the new EPLAN Data Portal
Data is the fuel for digital processes.
(Sophia Bulmahn, Director Product Marketing, Industrial Cabinet Solutions, Phoenix Contact)

EPLAN Data Portal
- Access high-quality online product catalogs from numerous component manufacturers
- Easily transfer component data to the EPLAN documentation
- Minimize the amount of effort required to maintain master data
- The new EPLAN Data Portal includes the data standard based on ECLASS

Use item data across processes
Standardized data is used in engineering tools and beyond. For example, it can be used in e-shops or catalogs. The item data is also useful for mechanical design, e.g., for imaging dimensions and connections.
Data for a wide range of applications
Item data, including commercial and technical features, is available via the EPLAN Data Portal. MCAD-relevant information, such as DXF data, is also available. In conjunction with the PARTcommunity, manufacturers also provide their CAD data for direct download. The ECLASS-standardized component data from Phoenix Contact can be downloaded in BMEcat format from the company’s website.
Your advantages for greater efficiency:
- Optimally coordinated engineering and manufacturing solutions
- Save time with access to standardized device data in the EPLAN Data Portal
- Access CAD data in various formats with PARTcommunity
- Download BMEcat data directly from the company website
Here we focus on end-to-end digitisation and consistent data provision in enclosure construction.
(Phillip Falkenhagen, Produktmanager Value Chain & Digitalization, EPLAN)

EPLAN Data Portal
- Access high-quality online product catalogs from numerous component manufacturers
- Easily transfer component data to the EPLAN documentation
- Minimize the amount of effort required to maintain master data
- The new EPLAN Data Portal includes the data standard based on ECLASS

Rittal PARTcommunity
- Download original component CAD data directly
- The data can be transferred to all popular CAD systems
- For greater flexibility, the level of detail for CAD models can be freely selected
- Quick preparation of design drawings with optimum planning certainty

Catalog management in BMEcat format
- Standardized exchange of catalog data in the versions BMEcat 2005 and BMEcat 2005.1 based on XML technology
- Secure basis with central access to all product information and options in the classification of articles
- Support of the internal organization and allocation of articles through classification
- Download of data classified by ECLASS or ETIM in BMEcat format from the Phoenix Contact website

The first step – from the initial idea to the finished product
Entry into the engineering process for a machine or system is defined in preplanning. The initial data is acquired at the earliest possible opportunity and is always refined further. The initial steps for component use in machine design are also defined.
Seamless integration for subsequent planning steps
The basic data is processed in EPLAN Preplanning, with seamless transfer to detail planning. Use of the initial components is also defined. Using configurations from the Rittal Configuration System, the CAD data is extracted and used for further processing.
Your advantages for greater efficiency:
- Customizable series portfolio with high availability
- Use EPLAN Preplanning to acquire engineering data, including sensor and actuator technology, at the earliest possible opportunity and utilize it across processes
- Configure and order products and corresponding accessories quickly and easily with the Rittal Configuration System
Digital data already supports engineering at an early planning and design stage.
(Jan-Henry Schall, Head of Technical Trainings & Rittal Innovation Center, Rittal)

EPLAN Preplanning
- Acquire structured engineering data from the beginning of the preplanning phase
- Import data from external sources, obtain graphical system or machine overviews
- Create data sheets or specifications for material procurement quickly
- Access the data collected in preplanning at any point in the engineering process

Rittal RiPanel
- Easy selection of an enclosure system
- Error-free accessory selection with verification checks, visual presentation and positioning in the 3D model
- Add machining options incl. CAD import of customer specific cut-outs
- Automatic generation of technical data and direct submission of an enquiry or order

EPLAN eBUILD
- Automatically create schematics based on EPLAN macro technology
- Design standards are available worldwide via the EPLAN ePULSE cloud environment
- Easily enter requirements via the self-explanatory configuration interface
- Access to ready-made libraries from Phoenix Contact with the free version, EPLAN eBUILD Free
- Getting started is possible without in-depth expert knowledge, IT or programming effort

Phoenix Contact clipx ENGINEER
- The clipx ENGINEER engineering software makes it possible to plan and procure terminal strips, assembled mounting plates, and junction boxes more efficiently than ever, and to seamlessly transfer the data to production – at every workplace.
- Create your function groups more efficiently with the use of functional engineering.
- Complete your electronics planning through automation with the necessary accessories.

Digital product development
In detail engineering, digital data takes center stage in product development and production. Engineering software is used to create circuit diagrams to provide an image of the automation project. Solutions for further product planning are connected via interfaces.
Closely interlinked engineering software
With EPLAN Electric P8, circuit diagrams are created using defined item data. PROJECT complete, PLCnext Engineer, and the EPLAN platform interact via standardized interfaces such as AutomationML. The CAD data from the configuration result can be extracted directly from the Rittal Configuration System and transferred to the mechanical design.
Your advantages for greater efficiency:
- Seamless communication from engineering through to manufacturing based on standardized data for individual products
- Cross-solution bidirectional data exchange, based on manufacturer-neutral interfaces such as AutomationML
- Digital imaging of the automation project for a transparent interdisciplinary planning process
Uniform and open data standards make it possible to seamlessly network every process stage.
(Dr. Andreas Schreiber, Vice President Industrial Cabinet Solutions, Phoenix Contact)

EPLAN Data Portal
- Access high-quality online product catalogs from numerous component manufacturers
- Easily transfer component data to the EPLAN documentation
- Minimize the amount of effort required to maintain master data
- The new EPLAN Data Portal includes the data standard based on ECLASS

EPLAN Electric P8
- Consistent, seamless, and fast engineering system for configuration in electrical design
- Automated reports and project documentation
- Engineering information provided for downstream processes

Phoenix Contact PROJECT complete
- The planning and marking software supports all phases of terminal strip configuration and provides individual and convenient process support, from electrical planning through to delivery of the finished product.
- PROJECT complete comes equipped with optimized interfaces to EPLAN P8/Pro Panel. With just a click of the mouse, the software imports the data from electrical planning and automatically designs the corresponding terminal strip.
- Intelligent functions automate many planning steps and provide significant time savings.

Phoenix Contact clipx ENGINEER
- The clipx ENGINEER engineering software makes it possible to plan and procure terminal strips, assembled mounting plates, and junction boxes more efficiently than ever, and to seamlessly transfer the data to production – at every workplace.
- Create your function groups more efficiently with the use of functional engineering.
- Complete your electronics planning through automation with the necessary accessories.

Phoenix Contact PLCnext Engineer
- Engineering software platform for Phoenix Contact automation controllers.
- Simplified engineering process, thanks to the use of automation modules and object-oriented programming.
- Time and cost savings, thanks to fully integrated programming in a single interface.
- Less work and training involved, thanks to the optimized user interface.

Rittal RiPanel
- Easy selection of an enclosure system
- Error-free accessory selection with verification checks, visual presentation and positioning in the 3D model
- Add machining options incl. CAD import of customer specific cut-outs
- Automatic generation of technical data and direct submission of an enquiry or order

EPLAN eBUILD
- Automatically create schematics based on EPLAN macro technology
- Design standards are available worldwide via the EPLAN ePULSE cloud environment
- Easily enter requirements via the self-explanatory configuration interface
- Access to ready-made libraries from Phoenix Contact with the free version, EPLAN eBUILD Free
- Getting started is possible without in-depth expert knowledge, IT or programming effort
Downloads

Using the digital twin in 3D planning
Control cabinet planning now goes 3D: the virtual prototype describes the planned system down to the smallest detail and provides all the important information for manufacturing. The digital twin prevents errors such as collisions and reduces costs as well as lead times.
Virtual prototype of the control cabinet
Configurations from the Rittal Configuration System are transferred to EPLAN Pro Panel, which is where control cabinet layout planning is performed. The 3D item data is available in the EPLAN Data Portal. Thermal Design Integration performs energy-efficient dimensioning for the climate control solution in control cabinets. PROJECT complete provides manufacturing documents based on terminal strip configurations. Configurators for customer-specific distribution block solutions and heavy-duty connectors simplify and speed up the process for creating a custom solution.
Your advantages for greater efficiency:
- Optimally coordinated data records and solutions for increased quality and efficiency across the entire product development process
- Profitable manufacturing starting from a batch size of 1 right through to series manufacturing
Both manual and automated manufacturing processes benefit from a complete digital twin of the enclosure.
(Phillip Falkenhagen, Produktmanager Value Chain & Digitalization, EPLAN)

EPLAN Data Portal
- Access online 3D item data from Rittal and Phoenix Contact
- Easily transfer standardized component data to the EPLAN documentation
- Minimize the amount of effort required to maintain master data

EPLAN Pro Panel Professional
- Design and construct control cabinets, switchgear, and power distribution systems in 3D
- Create electrical circuit diagrams, plan mounting layouts in 3D, and lay wires virtually
- The order information that is created and comprehensive manufacturing documents support automated control cabinet manufacturing

Thermal Design Integration
- Comprehensive concept consisting of digital product data, software-based configuration tools, and newly developed climate control solutions
- Thermal aspects are already taken into consideration during the control cabinet planning phase
- Verification of climate aspects and interactive planning of the best possible climate control solution

Rittal Therm
- Efficient and safe design of climate control components
- Easy calculation of the actual cooling capacity required – also when retrofitting or extending switchgear
- Calculation result can be used as detailed documentation

Rittal RiPanel
- Easy selection of an enclosure system
- Error-free accessory selection with verification checks, visual presentation and positioning in the 3D model
- Add machining options incl. CAD import of customer specific cut-outs
- Automatic generation of technical data and direct submission of an enquiry or order

Phoenix Contact PROJECT complete
- The planning and marking software supports all phases of terminal strip configuration and provides individual and convenient process support, from electrical planning through to delivery of the finished product.
- PROJECT complete comes equipped with optimized interfaces to EPLAN P8/Pro Panel. With just a click of the mouse, the software imports the data from electrical planning and automatically designs the corresponding terminal strip.
- Intelligent functions automate many planning steps and provide significant time savings.

Phoenix Contact clipx ENGINEER
- The clipx ENGINEER engineering software makes it possible to plan and procure terminal strips, assembled mounting plates, and junction boxes more efficiently than ever, and to seamlessly transfer the data to production – at every workplace.
- Convert your electronics planning into real items via bidirectional CAE interfaces.
- Use your trusted Phoenix Contact applications and configurators in clipx ENGINEER.
- Share and work on your projects locally or in a cloud.

Phoenix Contact customer-specific distribution block solutions
- PTFIX distribution blocks and single blocks offer countless possible combinations.
- The online configurator provides support in creating a custom distribution block solution.
- With straightforward menus, 2D and 3D product images, and intuitive user interfaces, the distribution blocks are configured by making just a few entries. Easy to create and order.

Phoenix Contact customer-specific heavy-duty connectors
- With the HEAVYCON online configurator you can create your own individual interface from countless housings and contact inserts
- Find the solution you want in just a few steps. The configurator supports you in choosing the right components
- Simply import the configured solution into your CAD system and check your plug connection in the 3D view
Downloads

When planning is finally completed and the full digital description and resulting parts lists of components and modules have been created, the data is transferred to the subsequent processes for procurement and purchasing. To enable a continuous digital connection here as well, we offer suitable software solutions that ensure error-free and secure data transmission.
Here, it is often not only important to transfer parts lists to the ERP system, but also to quickly provide information about availability, individual pricing, and similar, all of which speeds up and simplifies the overall process.
Procurement process with a comprehensive database
Direct data transfer from the comprehensive digital description of the control cabinet to the systems for the procurement process can be a significant advantage here by helping to prevent errors, save time, and thus increase efficiency. The data of the configurated solutions can also be transferred directly to the respective online shop. There the information about price, availability and delivery time is immediately displayed.
The EPLAN Integration Suite creates the interfaces to all systems involved in the process.
Terminal strips are planned using PROJECT complete. They can be ordered easily thanks to the link to the Phoenix Contact online shop. Rittal customers can also benefit from digital processes: from integration and virtual product configuration right through to ordering via the Rittal online shop. The EPLAN Integration Suite establishes connections to all systems involved in the process.
Your advantages for greater efficiency:
- Direct connection between planning systems and ERP and PDM systems enables bidirectional data exchange
- Digitally integrated interfaces enable error-free and rapid processes
- Integrated configurators enable the provision of individual information – quickly and verified by a plausibility check
The digital representation of the complete enclosure forms the “single source of truth” for production.
(Thorsten Freytag, Produktmanager Value Chain & Digitalization, Rittal)

Phoenix Contact PROJECT complete
- The planning and marking software supports all phases of terminal strip configuration and provides individual and convenient process support, from electrical planning through to delivery of the finished product.
- The terminal strips are ordered directly via PROJECT complete (currently only available in Germany).
- Parts lists are transferred to the Phoenix Contact online shop, where the price calculation and availability information is displayed straight away.

Phoenix Contact clipx ENGINEER
- The clipx ENGINEER engineering software makes it possible to plan and procure terminal strips, assembled mounting plates, and junction boxes more efficiently than ever, and to seamlessly transfer the data to production – at every workplace.
- Order your items directly from the software package via the connection to the Phoenix Contact online shop.

Rittal RiPanel
- Easy selection of an enclosure system
- Error-free accessory selection with verification checks, visual presentation and positioning in the 3D model
- Add machining options incl. CAD import of customer specific cut-outs
- Automatic generation of technical data and direct submission of an enquiry or order

Rittal online shop
- Order the appropriate product quickly and easily online and conveniently track orders
- Display of prices, including individual discount
- Import shopping carts into your own e-procurement system via OCI interface
- CAD drawings in numerous different formats can be selected for each product

Phoenix Contact online shop
- Order products and configured terminal strips
- Immediate price calculation and information on the availability of the products
- Manage individual items and price lists
- Convenient order tracking

EPLAN Integration Suite
- Integrate EPLAN data into existing ERP, PDM, and PLM system landscapes
- Greater transparency in the overall product development process

Phoenix Contact printing service
- Customer-specific markings can be created quickly and easily with PROJECT complete and ordered online.
- All materials that can be marked according to customer requirements are indicated with the “Printed for you” symbol and are available on our website for you to specify your individual printing requirements.
- You can use marking materials in UniCard and UniSheet format as well as metal labels for color printing.
Downloads

Digital manufacturing integration
Based on a standardized description, a product data model of the control cabinet is provided for subsequent production processes. It includes all the necessary information required for both manual and automated panel building.
Complete product description for manufacturing
Using the AutomationML interface, all relevant data can be exported from EPLAN Pro Panel Professional, refined further in PROJECT complete, and finally passed on to manufacturing.
Your advantages for greater efficiency:
- Smart automation of subprocesses in engineering
- Central provision of a digital product description of the complete control cabinet, including all the data required for the manufacturing process
Digital networking of engineering and purchasing significantly reduces administrative effort.
(Christian Großmann, Director Development, Industrial Cabinet Solutions, Phoenix Contact)

EPLAN Pro Panel Professional
- Design and construct control cabinets, switchgear, and power distribution systems in 3D
- Create electrical circuit diagrams, plan mounting layouts in 3D, and lay wires virtually
- The order information that is created and comprehensive manufacturing documents support automated control cabinet manufacturing

Rittal RiPanel
- Easy selection of an enclosure system
- Error-free accessory selection with verification checks, visual presentation and positioning in the 3D model
- Add machining options incl. CAD import of customer specific cut-outs
- Automatic generation of technical data and direct submission of an enquiry or order

Phoenix Contact PROJECT complete
- The planning and marking software supports all phases of terminal strip configuration and provides individual and convenient process support, from electrical planning through to delivery of the finished product.
- Data used as manufacturing documents for the control cabinet layout as well as component marking
- Export of assembly data in AutomationML format for automatic DIN rail assembly

Phoenix Contact clipx ENGINEER
- The clipx ENGINEER engineering software makes it possible to plan and procure terminal strips, assembled mounting plates, and junction boxes more efficiently than ever, and to seamlessly transfer the data to production – at every workplace.
- Plan your terminal strips, assembled mounting plates, and junction boxes realistically in 3D.
- Use the production documentation generated from your project easily for the documentation and subsequent process steps.
- Control your workflow via the direct connection options to production systems.

Rittal RiPanel Processing Center
- Central planning and up-to-date overview of the utilization of individual machines (Rittal Perforex MT, Rittal Secarex).
- Current status display of production orders and machine orders
- Direct interface to EPLAN Pro Panel
- Maximised schedule reliability with optimised planning certainty
Downloads

Digital all the way to production
All manufacturing steps are automatically derived from the information for the virtual prototype. All the necessary machine programs can be created automatically through direct communication with the Human Machine Interfaces of modern automation solutions. Manual manufacturing is also supported digitally.
From the digital twin to the real product
The digital twin provides input for manufacturing systems such as Rittal Perforex and various semi-automated machines, fully automated wire processing machines, and printing systems. Data can also be used for additional services, such as Phoenix Contact’s terminal strip service.
Your advantages for greater efficiency:
- Intelligent support of manual manufacturing processes
- Automation solutions for cost efficiency and high product quality
- Flexible services for custom order situations
The seamless interplay between design engineering and configuration ensures simple and error-free construction of the complete enclosure.
(Thorsten Freytag, Produktmanager Value Chain & Digitalization, Rittal)

Rittal Perforex MT
- Fully automated hole-drilling, thread-tapping, and milling of cut-outs and housings with the
- Convenient data import of common CAD systems and planning tools such as .dxf, EPLAN Pro Panel, RiPanel Processing Center and Rittal Configuration System

Rittal Perforex LC
- 3D machining of powder-coated sheet steel and stainless steel housings as well as mounting plates, doors, side panels, and roof sheeting
- Convenient data import of common CAD systems and planning tools such as .dxf, EPLAN Pro Panel and Rittal Configuration System

Phoenix Contact PROJECT complete
- The planning and marking software guides you through all phases of terminal strip configuration
- Provides digital documents for terminal strip production
- Integration with interfaces to all common CAE programs
- Intuitive software operation with customizable user interface
- Ordering of terminal strips in real time with direct connection to the Phoenix Contact e-shop

Phoenix Contact automatic devices
- Cutting, stripping, and crimping: automating these steps provides cost-effective advantages, even for small and medium-sized batches
- High functionality, fast setup times, and consistently high-quality results
- Easy startup with Plug and Play and intuitive operation

Rittal cutting center Secarex
- Fast and precise cutting of cable ducts and DIN rails
- Project-specific marking with the integrated label printer
- Cutting process optimized across multiple projects
- Interface to EPLAN software and Perforex machinery

Rittal busbar machining CW 120
- Bending, punching, and cutting of copper and aluminum busbars
- Flexible and easy handling, high bending and punching precision, efficient and ergonomic operation, easy tool change
- The integral precision laser facilitates the cutting and bending process

Phoenix Contact clipx WIRE assist
- The worker assistance system for efficient conductor preparation
- Modular workstation design, mobile use, and optimum positioning of automatic devices, tools, and material
- Convenient application with intuitive user interfaces and simple CAE data transfer
- Process reliability, thanks to software-supported conductor preparation with direct device control

Phoenix Contact marking systems
- Create markings easily: whether with a laser marker, high-speed printer with UV LED technology or a thermal transfer printer
- Wide range of marking technologies provide the right solution for marking terminals, wires and cables, equipment, and plants
- The right solution for every application in industrial identification, thanks to various marking materials

Rittal Wire Terminal WT C
- Fully automated wire end processing with ferrules
- Management of up to 36 different wires and sequential or order-specific wire output in an ordering system
- Full networking from the E-CAD tool through to the manufacturing processes
- The assembled wires can be processed via EPLAN Smart Wiring

Rittal semi-automated machines
- Assembly of wiring cables: cutting, stripping, and crimping
- Pneumatically or electrically driven cable assembly
- Interfaces to the PC or to CAE data in EPLAN Pro Panel (depending on the model)

Phoenix Contact terminal strip service
- Supply of pre-mounted and marked terminal strips including accessories, ready for installation and connection.
- The terminal strip service provides help in managing order peaks flexibly, and enables terminal strips to be supplied just in time for series production.
- Terminal strip configuration via the PROJECT complete configuration software with online transfer of the parts lists to the Phoenix Contact e-shop.

Phoenix Contact marking app for smartphone and tablet
- Intuitive operation: The THERMOMARK GO can be fully operated with the MARKING system app
- Application Guide: with just a few clicks, get easy and efficient the right marking solution
- The app is available for Android and iOS
- Automatic updates: the latest software version available at any time
- Guided creation of application-specific and standard-compliant labeling solutions

Phoenix Contact clipx WIRE assist Software
- The necessary wiring information is exported from EPLAN PRO Panel and fed into the clipx WIRE assist software.
- Based on this data, the clipx WIRE assist software guides the worker through the semi-automated wire preparation process.
- At the same time, the devices in the worker assistance system are controlled directly and the necessary information for further processing and wiring is displayed on the monitor.
- In addition, an integrated editor function also allows data to be created or supplemented manually.

Phoenix Contact Hand tools
- Cutting, stripping, crimping, mounting, and measuring – Phoenix Contact provides you with the best hand tools for every application in electrical engineering.
- Discover the high-quality processing and measuring tools from our tools product range.
- As a system supplier, we have a range of products that includes standardized ferrules and connectors and crimping tools designed to work with them for reliable processing.

Phoenix Contact Automatic devices
- Cutting, stripping, and crimping: Automation of these sub-steps ensures economic benefits even with small to medium quantities
- High functionality, quick setup time, and a lasting high level of quality in the work results
- Simple commissioning thanks to Plug and Play and intuitive operation
- As a system supplier, we have a range of products that includes standardized ferrules and connectors as well as crimping devices designed to work with them for reliable wire preparation.

Phoenix Contact Wire duct and DIN rail cutters
- With the profile and DIN rail cutters from Phoenix Contact, you can cut a wide variety of DIN rails and wiring ducts quickly, without much effort, and with precision.
- Ensure a clean and safe work environment: Cut plastic or metal profiles without burrs.
- Follow-up work, like deburring when sawing, is not necessary.
Downloads

Virtual assistant simplifies manual mounting
Software-based assistance systems provide support when assembling and installing wiring connections. All the necessary data for mounting control cabinet modules, such as terminal strips, is provided as required. Manual mounting activities are also supported by smart solutions.
EPLAN Smart Wiring guides the worker through the wiring process step by step. They have an overview of everything, even without a circuit diagram. The same is true for scenarios where multiple control cabinets are wired in parallel or different colleagues work on the same project. The required wires are assembled at the Rittal Wire Terminal. Handling systems such as the Rittal assembly frame and the Smart Lifter provide support for manual activities.
Your advantages for greater efficiency:
- Manufacturing and installation processes are much simpler
- Easy monitoring and documentation
- Convenient solutions make it easier to perform manual mounting activities
Digital data-enabled assistance systems are the key to secure and efficient assembly processes.
(Phillip Falkenhagen, Produktmanager Value Chain & Digitalization, EPLAN)

EPLAN Smart Mounting
- Digital worker guidance for mounting mechanical and electrical components in the control cabinet
- Workers are guided step-by-step through the manual activities and receive visual support in 3D at each step
- Central order management and progress overview for workers and production management

EPLAN Smart Wiring
- Step-by-step guide for easy wiring without a circuit diagram
- From the terminal point to the exact installation route, all the necessary information is provided in digital form – also in 3D if required
- Status information facilitates project handover between different employees and enables project monitoring

EPLAN eVIEW
- Digital review of circuit diagrams with redlining and greenlining
- Location-independent single source of truth for defined users
- Circuit diagrams are always up-to-date, even after project completion
- Data security ensured by the ePULSE Trust Center

Rittal assembly frames
- Easy and variable fixing of mounting plates with a quick-release fastener
- Minimal space requirements when not in use
- Individually positionable in the workshop due to being independent from the power grid
- Easy handling due to four castors including total lock function

Rittal Wire Station
- Flexible and efficient use for assembly and wiring activities in the workshop
- Electrically adjustable height for ergonomic work
- Multiplex worktop with integrated ruler
- Workstation with integrated socket strip and shadow board for Rittal tools

Rittal Smart Lifter
- Easy transportation of bayed control cabinets in the workshop or at the installation site
- Supports the simple mounting of bases beneath control cabinets
- Flexible use for control cabinets of different depths, thanks to adjustable forks
- Ergonomic lifting and lowering with a torque crank

Phoenix Contact Hand tools
- Cutting, stripping, crimping, mounting, and measuring – Phoenix Contact provides you with the best hand tools for every application in electrical engineering.
- Discover the high-quality processing and measuring tools from our tools product range.
- As a system supplier, we have a range of products that includes standardized ferrules and connectors and crimping tools designed to work with them for reliable wire preparation.

Phoenix Contact clipx WIRE assist
- The worker assistance system for efficient wire preparation
- Modular workplace design, mobile work possible, and optimal positioning of tools and automatic devices
- Convenient use through intuitive user interfaces and simple CAE data transfer
- Process reliability through software-supported wire preparation with direct device control

Phoenix Contact clipx WIRE assist Software
- The necessary wiring information is exported from EPLAN PRO Panel and fed into the clipx WIRE assist software.
- Based on this data, the clipx WIRE assist software guides the worker through the semi-automated wire preparation process.
- At the same time, the devices in the worker assistance system are controlled directly and the necessary information for further processing and wiring is displayed on the monitor.
- In addition, an integrated editor function also allows data to be created or supplemented manually.

Phoenix Contact labeling and application systems
- For the first time ever, the THERMOMARK E SERIES marking system combines and automates several process steps in the identification process, thereby enabling a considerable increase in efficiency in this time-consuming undertaking.
- Time savings of around 60% with printing and application in a single process step.
- Flexible response with the modular system comprised of a standard thermal transfer printer and four applicators for different identification solutions.
- Consistent digital workflows.
- Easy handling and constantly high quality with the automated process.

Phoenix Contact tool-free wiring
- Maximum ease of use thanks to the force-saving Push-X and Push-in technology
- Reduced assembly times - due to the clever spring design, direct wiring is possible without tools
- High flexibility in conductor selection - with Push-X and Push-in, both rigid and flexible conductors can be wired effortlessly
- Full compatibility with the CLIPLINE complete modular terminal block system enables the use of standardized accessories
Downloads

Digital support for manual product testing
Many quality tests can already be performed digitally. However, when it comes to testing the actual function and installation, this is still carried out on the real end product. Software-based assistance systems and digital models enable guided testing of the end product.
Digital quality assurance
EPLAN Smart Wiring enables tests to be performed with automated logging in the control cabinet wiring. Quality assurance is therefore supported digitally through integration in the workflow.
Your advantages for greater efficiency:
- Intelligent assistance system for testing the wiring
- Digitally supported tests provide quality assurance for the end product
Digital support and logging of functional and quality testing ensure safety.
(Jan-Henry Schall, Head of Technical Trainings & Rittal Innovation Center, Rittal)

EPLAN Smart Mounting
- Digital worker guidance for mounting mechanical and electrical components in the control cabinet
- Workers are guided step-by-step through the manual activities and receive visual support in 3D at each step
- Central order management and progress overview for workers and production management

EPLAN Smart Wiring
- Step-by-step guide for easy wiring without a circuit diagram
- From the terminal point to the exact installation route, all the necessary information is provided in digital form – also in 3D if required
- Status information facilitates project handover between different employees and enables project monitoring

EPLAN eVIEW
- Digital review of circuit diagrams with redlining and greenlining
- Location-independent single source of truth for defined users
- Circuit diagrams are always up-to-date, even after project completion
- Data security ensured by the ePULSE Trust Center

Phoenix Contact Testing and measuring equipment
- The high-quality multimeters, current probes, and voltage testers offer impressive robustness and multifunctional applications.
- Our products are tested and approved in accordance with the applicable national and international standards.

Tailored hardware and software solutions
Using software that is optimally tailored to the hardware used enables fast product startup. Furthermore, faster communication is possible between engineering and manufacturing based on standardized data for individual products.
Easy programming
PLCnext Engineer is the flexible PLC programming software for the PLC generation with PLCnext Technology. It combines all of the basic functions needed for configuration, programming, visualization, and diagnostics.
Your advantages for greater efficiency:
- Optimally coordinated portfolio of software and manufacturing solutions
- Seamless communication between engineering and manufacturing based on standardized data for individual products
Digital redlining and greenlining enable a consistent exchange of information between engineering and production.
(Dr. Andreas Schreiber, Vice President Industrial Cabinet Solutions, Phoenix Contact)

EPLAN eVIEW
- Digital review of circuit diagrams with redlining and greenlining
- Location-independent single source of truth for defined users
- Circuit diagrams are always up-to-date, even after project completion
- Data security ensured by the ePULSE Trust Center

Phoenix Contact PLCnext Engineer
- Engineering software platform for Phoenix Contact automation controllers.
- Fast startup with intuitive operation, easily diagnosable controller status, and online verification of input and output signals.
- Flexible engineering through the integration of individual add-in functions in the free basic version
- Secure programming, certified in accordance with IEC 61508

Phoenix Contact QUINT POWER customized parameterization
- With the QUINT POWER app for your mobile end device or the QUINT POWER software for your PC, you can parameterize your power supply easily and precisely
- Set signaling thresholds and the output voltage
- Adapt characteristic curves individually

Rittal ePOCKET
- Central storage of machine documentation (digital wiring plan pocket)
- Fully digital process representation
- Always work with the latest version of documentation
- Tracking of changes in the project, including notifications
- Access to projects or documents via QR codes

Current status can always be determined
Status data, process data, and parameterizations can be managed via cloud-based services during active control cabinet operation. Clear component marking with a QR code or RFID tag enables easy identification on site via an app.
Smart Services for operation
Smart Services like the Device Management Service from Phoenix Contact enable smart devices to be managed and monitored via PROFICLOUD – anytime, anywhere. The Rittal Smart Service Portal enables service processes to be increasingly automated. With EPLAN eVIEW, up-to-date machine and system documentation is always available in the cloud during servicing.
Your advantages for greater efficiency:
- Solutions for control cabinet operation for the implementation of predictive maintenance and efficient maintenance processes
- Current operating status always available at a glance
- Cloud-based status management and app-based identification on site enable quick action to be taken during servicing
Digital redlining and greenlining enable a consistent exchange of information between engineering and production.
(Dr. Andreas Schreiber, Vice President Industrial Cabinet Solutions, Phoenix Contact)

Phoenix Contact PROFICLOUD
- Comprehensive cloud solution for smart devices
- Smooth entry into the world of digitalization with ready-to-use IoT solutions
- Flexible access to data with Smart Services
- Easy expansion and scalability with dynamic IT resources
- Secure communication between the smart devices and Proficloud via TLS encryption

Phoenix Contact smart devices
- Smart devices from Phoenix Contact can be managed and monitored via the Device Management Service – anytime, anywhere
- Direct overview of device information, such as the device type, serial number, and installed firmware and hardware version, in the form of a digital rating plate
- State of health (SoH) and connection status, plus current and historical logs, are always visible at a glance

Phoenix Contact smart devices
- With the IoT-capable EMpro, data can be sent directly and securely to the cloud via a router. This enables flexible access to measured data and component data thanks to Proficloud Smart Services.
- ImpulseCheck is the intelligent assistance system for surge protection in the field of mains protection. The module can be used to measure the state of health (SoH) of every single protective device via cloud connection. Thanks to real-time measurement of surge currents and transient overvoltages, it is possible to continuously monitor the condition of the system and surge protection.

Phoenix Contact THERMOMARK GO
- Create markings on site: control the label printer via a smartphone or tablet
- Modern interfaces: connect the smart device via Bluetooth or NFC
- Intuitive label configuration: MARKING system app guides users through the marking process
- Marking made easy: automatic material recognition prevents printing errors
- Large variety of applications: more than 100 materials with pre-punched labels and continuous media

Phoenix Contact MARKING system services
- Smooth operation, thanks to professional installation and training on site
- Devices are always in top condition, thanks to regular maintenance
- Sustainable marking concept, thanks to the repair service which uses original parts
- Reliable support from the Technical Support team
- No downtimes, as leased devices are provided during repair and maintenance work, or at peak order times if additional capacity is required

Rittal Smart Service
- Networking of Rittal products and transfer of operating data to the certified Smart Service Cloud
- Visualization of service processes with the Smart Service Portal as a basis for providing situation-specific recommendations for action
- Permanent monitoring of devices and data-based remote diagnostics
- Automated handling of service processes

EPLAN eVIEW
- Digital review of circuit diagrams with redlining and greenlining
- Location-independent single source of truth for defined users
- Circuit diagrams are always up-to-date, even after project completion
- Data security ensured by the ePULSE Trust Center

Phoenix Contact QUINT POWER customized parameterization
- With the QUINT POWER app for your mobile end device or the QUINT POWER software for your PC, you can parameterize your power supply easily and precisely
- Set signaling thresholds and the output voltage
- Adapt characteristic curves individually

Phoenix Contact Services automatic devices
- Expert consultation on the products and applications
- Support during commissioning and instruction by phone, online, or on-site
- Professional repair, maintenance, and calibration service
- Provision of devices on loan

Rittal ePOCKET
- Central storage of machine documentation (digital wiring plan pocket)
- Fully digital process representation
- Always work with the latest version of documentation
- Tracking of changes in the project, including notifications
- Access to projects or documents via QR codes
